These mirrors were carried by fighter pilots to signal to rescue crews if they were downed, particularly behind enemy lines.This mirror was carried by Max Carland part of his kit while flying missions from MorataiRectangular mirror with instructions on reverse side. Front is mirror, back is black with 50mm round mirror with sighting cross in centreEmergency signaling mirror (ESM/1) Sec.No. 4063 General Electric Company

This is an Army Air Corp procured signal mirror that dates from September 1943 (Ser No 40653)This mirror was adopted for use by Army Air Force (US?) in September 1943Oblong mirror face one one side, painted instructions on one side, with printed instructions for use. There is a whole on the bottom left corner with a rope for personal attachment.Specification Number 40653 General Electric Companymirror, emergency, signals, us, army air force

Emergency signaling mirror issued to Lt Gen Brian “Ash” POWER. These are designed for long-distance distress signaling in sunny conditions, with laminated glass or durable materials that can reflect sunlight for miles. The circular crosshatched section (aiming aperture) in the center, allows users to precisely direct the flash at aircraft or ships.Oblong shaped mirror with circular cross hatched section in the centre. Is housed in black half case with red writing. Long cord attached through hole in mirror.Rear side - Mirror Signalling Instructions in red letteringlt gen ash power, army, signaling mirror, mark3 type ii

Signalling Mirrorequipment, various, army

Instructions for signalling in plastic sleeve with signalling mirror.

Items belonged to Maxwell Lennox Matheson No 418447 RAAF. Refer Cat No 1959 for his service record..1) Emergency signaling mirror with cord and aiming post made of polished metal. .2) Bag to carry mirror made of cotton.Has instructions on the back of mirrormilitary equipment, signalling, mirror

This emergency kit was carried by Merv Schneider when flying missions out of Northern Australia.Red colour case with transparent lid packed tightly with various medical supplies, powders, ointments, drugs, dressings, razor blades and small signaling mirror. Emergency Sustenance Type E-3 Specifications Number 94-40441 Air Forces, U.S. Army.emergency kit, survival kit, merv schneider, medical

A.J.Abicair was C/O of 486 Maintenance Squadron from 22/08/1946 having been promoted to A/W.Cdr in May 1944 , then T/OT/W/Cdr. January 1945. .Part of the collection of Wing Commander A.J.Abicair issued equipment.Rectangular mirror with see through cross in centre on front. Instructions for use printed on rear. Cord threaded through corner hole. Contained in original cardboard container.One Emergency Signalling Mirror ESM/1. "Spec. 40653" Open this end and pull lanyard. This package contains 1 emergency signalling mirror with which the attention of persons in the distance (in ships, aircraft, etc) may be attracted by a beam of reflected sunlight. A positive means of aiming the reflected beam of light is provided.Instructions are printed on the other side of this package and on mirror. General Electric company. Instruction for use are written on the rear. From collection of Wing/Com A.J. Abicair

Belonged to Victor Henry Evans No 418655 RAAF. Refer Cat No 1760.4..1) Emergency Signalling Mirror (ESM/1). Metal, rectangular shape with rounded corners. One side is the mirror, the other side has instruction points 1-3. .2) plaited cord attached to mirror frame. "SPEC 40653" " General Electric Company"signalling, mirrors, emergency, raaf

MIL-M-18371E DSA-400-70-C-1361

Emergency signaling mirror - Ground to Air .1) Bright polished steel. Cross hairs engraved on reflective surface. Rear face has instructions for use, yellow sticker with black print. .2) Sight. Long piece with viewing hole at end, painted white. .3) White cotton container with tie straps..1) On rear yellow sticker / black print: "Instructions for use of Heliograph Mirror & illustration" .2) Site stamped one side: "27H / 2107" .3) Faded stencil on flap: "Heliograph" heliograph, mirror, ground to air

The item was possibly issued Air Force personal in the event of being shot down ..1) Rectangular webbed canvas bag with attached flap lid secured with metal press studs and belt hook. .2) Emergency signalling mirror, black background, orange coloured printed directions on the non reflective side and mirror central. .3) & .4) Plastic rigid containers with a metal spring clasp contains medical/survival supplies and directions for use. .3) contains the medical supplies and .4) unclear what some are but has razor blades, sewing kit fishing line and hook kit.survival kit, emergency

Emergency survival kit made safe and watertightThe kit represents equipment used around the time of World War II to aid the safety and survival of seafarers.Survival kit, 1973. Rectangular metal box with round screw top lid that has wing handles with a red cross on both ends of box (one end is heavily rusted). Contents of box includes booklet 1943 "Advice to Those in Lifeboats and Rafts of Merchant Ships" and one rectangular piece of water resistant paper with "Advice-books" written on it (separated from booklet), cylindrical stainless steel container with wire handle, cotton bandage. Also inside, one Sun-flash Distress Signal Mirror (instructions adhered to back) with padded pouch, labelled "MIRROR" in white paint, and a card inside pouch, adhering to insides. Metal is corroding.White painted label on pouch 'MIRROR". Paper instructions on back of mirror headed "_ _ FSON SUN-FLASH DISTRESS, SIGNAL DEVICE". Printed on waterproof cover "ADVICE BOOKS". warrnambool, flagstaff-hill, flagstaff-hill-maritime-museum, shipwreck-coast, survival kit, commonwealth of australia, sun-flash distress signal mirror, survival advice book, military supplies, emergency kit, survival kit.

The Heliograph MkV is a fascinating piece of historical surveying and communications equipment. It was primarily used for visual signaling by reflecting sunlight with a mirror to send coded messages over long distances. This method was primarily useful in remote areas where other forms of communication were not available. The MkV model, specifically, was widely used by the British Army and other military forces from around 1906 until the mid 1960s. It remained in use with the Australian Army Survey Corps until the mid 1980s. The device typically included a 5 - inch mirror and was often mounted on a tripod for stability. Initially the instrument was used to communicate between survey stations using Morse code to coordinate their activities. Later when better forms of communication were available, they were used for precise angle alignment where the sunlight reflection from the mirror was targeted between the survey stations to give very accurate results. The MkV was relatively light weight and portable, making it ideal for use in the field. It could be setup and adjusted quickly. The heliograph had an adjustable mirror that could be tilted to reflect sunlight towards a distant receiver. Surveyors could align the mirror using a sighting device. Whilst it was primarily used by the Military it was also used in civil surveying particularly in the remote areas of Australia. The British Army Mark V version uses a flat round mirror with a small unsilvered spot in the centre. The sender aligned the heliograph to the target by looking at the reflected target in the mirror and moving their head until the target was hidden by the unsilvered spot. Keeping their head still, they then adjusted the aiming rod so its cross wires bisected the target, they then turned up the sighting vane, which covered the cross wires with a diagram of a cross, and aligned the mirror with the tangent and elevation screws, so the small shadow that was a reflection of the unsilvered spot hole was on the cross target. This indicated that the sunbeam was pointing at the target. If the sun was in front of the sender, its rays were reflected directly from this mirror to the receiving station. If the sun was behind the sender, the sighting rod was replaced by a second mirror, to capture the sunlight and direct it onto the main mirror to reflect it to the receiving station.. 1 Brish Army "Mance" Mk V A253 Heliograph has two 125mm diameter mirrors on a brass arm with targeting attachments. The Instrument is mounted on a three-legged tripod of brass and mahogany with spiked feet, approximately 1.2 metres high. The instrument was made by LUCO Art Metal Co Ltd, London in 1940. .2 A military green metal carrying safety storage case with khaki shoulder strap.A253 stamped on instrumentroyal australian survey corps, rasvy, fortuna, army survey regiment, army svy regt, asr

The Heliograph MkV is a fascinating piece of historical surveying and communications equipment. It was primarily used for visual signaling by reflecting sunlight with a mirror to send coded messages over long distances. This method was primarily useful in remote areas where other forms of communication were not available. The MkV model, specifically, was widely used by the British Army and other military forces from around 1906 until the mid 1960s. It remained in use with the Australian Army Survey Corps until the mid 1980s. The device typically included a 5 - inch mirror and was often mounted on a tripod for stability. Initially the instrument was used to communicate between survey stations using Morse code to coordinate their activities. Later when better forms of communication were available they were used for precise angle alignment where the sunlight reflection from the mirror was targeted between the survey stations to give very accurate results. The MkV was relatively light weight and portable, making it ideal for use in the field. It could be setup and adjusted quickly. The heliograph had an adjustable mirror that could be tilted to reflect sunlight towards a distant receiver. Surveyors could align the mirror using a sighting device. Whilst it was primarily used by the Military it was also used in civil surveying particularly in the remote areas of Australia. This instrument was used as a training aid to help teach surveyors at the Royal Australian Survey Corps School of Military Survey. Catalog item No 2009 is a tripod that was used to mount the Heliograph whilst being used for surveying.A Heliograph containing two mirrors with brass surrounds mounted on a wooden board as a Training Aid. Item has additional parts attached to the base board."Heliograph Mk V Training Aid"royal australian survey corps, rasvy, fortuna, army survey regiment, army svy regt, asr

.1) Goggles, black plastic frame, foam padding, black strap. Brand name Oakley. .2) Camouflage paint in plastic container, hinged lid with mirror inside. 3 divided sections with dark green, light green & brown used paint. .3) Patch, square, at top - yellow, middle - white above blue, bottom - bright light green. .4) Foot powder in dark green plastic container, twist lid with holes. .5) Container, dark green plastic cylinder, 11 matches, assorted. .6) Container lid, snap on, for .5). .7) Tube of army personal insect repellent. Dark green plastic tube with screw top lid, unnumbered. Instructions & warnings printed on back of tube. .8) Metal signalling plate, Polished steel signalling plate with small hole in center. Instructions printed on one side. .9) Vinyl sleeve for signalling plate, green. Dole K.1) Written on foam in black texta: DOLEY. .2) Austcam NSN 6850-36-130-0172. Military Sunscreen DDM↑ 0598. .4) Foot Powder, Colbar Pty Ltd, 50g net, B/C 5-98, Formula Salicylic Acid 3%, Starch 10%, Talc 87%. .7) NSN 6840-66-106-0247.military equipment, containers, preventative medicine, goggles

Items relate to Clifford Alfred Cairncross, (born Brighton, enlisted Melbourne) in the RAAF on 4.6.1942 No 56931 age 28 years. At discharge on 16.4.1946 he held the rank of LAC in No 40 Operational Base unit..1) Map of ocean curents & surface winds west pacific area - on silk fabric (Nov - Apr). .2) Heliograph mirror & foresight, glass & metal with printed instructions on mirror back. .3) Cotton pouch to hold heliograph. .4) 1 Pair black leather large pilot's gloves .5) 1 Pair brown leather pilot's gloves .6) Aircraft recognition US Navy book .7) Brown leather document pouchdocuments - maps, costume accessories, glove accessories, communications - signals, containers, books - reference

Belonged to Keith David Livingston VX136969 2nd AIF. Refer 1911P for service history.Shaving mirror in leather wallet. .1) Wallet made of brown leather stamped in gold. .2) Polished metal mirrorOn wallet in gold, “Good luck”mirrors, leather, pouches, signalling, wwii, world war two, second world war, wallets

A spare parts kit for a signalling Heliograph, the kit is incomplete. This kit is in a circular, metal carrying case and contains a spare 5 inch mirror and six brown paper discs. The case has a knurled rim and a small metal loop for carrying or attaching to equipment. The case has paper label with the inscription "HELIOGRAPHS 5-in MARK V (AUST.)" and a list of the contents. The other side of the case has the "D^D" symbol. The rear side of the mirror is marked with the 'D^D' symbol and the manufacturers name. "Manufactured by SOUNDCRAFT PTY LTD Sydney"ww1, army, mirror, heliograph, spare kit, signalling, spare parts

A mirror assembly complete with holder and swivel for the 5" MK.V signalling heliograph used by British and Commonwealth Defence Forces.

Mirror blackened on one side. 5cm.circular clear area in the centre. This circular area has a green cross in the middle. There is a 1 cm. hole in the lower left corner.Useage instructions are printed in amber on the face side.

Dark blue printed instructions on paper mounted on a buff coloured cardboard card.LAMPS, SIGNALLING DAYLIGHT, SHORT RANGE Lamp can be used either (1) on the spike and spike extension stuck in the ground or (2) in the hand if necessary, or (3) withe the adaptor provided on a standard helio stand. SIGHTING TUBE: It is important to see that the lamp is so aligned that the distant receiving station is at the centre of the cross slots and maintained in that position the whole time that signals are being sent. BULBS: when fitting a new bulb, insert the locating tongue on the washer to the front and push the stem right back in the slot. BATTERIES: The correct replacment unit for this set is 8 "S" cells connected "in series". Screw up both terminal nuts tightly, ans see thar all connectors are in position. NIGHT SIGNALLING: An adjustable screen is supplied for reducing the light and one of the colour discs should always be used in conjunction with it when signalling at night under enemy observation. KEY CONNECTIONS. Use the two-pin plug in No.1 socket as long as the light is good enough, then cahnge to No.2. This will greatly lengthen the life of bulb. Used bulbs and batteries should not be relaced in the box, but discarded and a fresh supply obtained. Get a copy of detailed instructions "How to Use" this signalling outfit. KEEP LENS, MIRROR, BULB AND FRONT GLASS CLEAN.instructions, lamp, signalling, daylight, short range

Distress signalling device from the SS Time. 5. Mirrors: Better known as a Heliograph, a mirror might be used while onboard and mostly on a survival craft to reflect the sunshine towards the entity that one needs to attract the attention of. These mirrors not only reflect the light to pinpoint the location of the emergency but are also non-corrosive at the same time. This helps to prolong their usage for a longer period of time.Robertson sun-flash distress signal device with original cardboard boxInstructions on back of mirror and on cardboard boxheliograph, distress signalling, ss time

Bright metal square-shaped mirror with round viewing holeBCB (in corner)signals, mirror, sas

This portable, hand held visual signalling lamp was used for optical communication via Morse code. It comprises the metal encased Aldis lamp with electrical cord and its associated green-painted, hinged wooden carrying case, which has a metal clasp and leather hand grip. Larger versions of these lamps are fixed on ships or pedestals and have shutters on the front that are opened and closed to transmit signals. Smaller hand held versions like the Point Hicks example have a concave mirror that is tilted to focus the light into pulse signals via a trigger. The lamps were pioneered by the British navy in the late nineteenth century and continue to be used to the present day.317 Details on the Point Hicks lamp include a serial number and other information. Another Aldis lamp and case remaining at Cape Nelson Lightstation dates to 1960 and has the initials of the Department of Transport, which at that time incorporated the Commonwealth Lighthouse Service. Wilsons Promontory also has an Aldis lamp and case that dates from around the same year. A lamp formerly at Cape Schanck has disappeared. The Aldis lamp and associated case at Point Hicks has first level contributory significance for its historic values and provenance to the lightstation. PHLS0007.1 Hand held signal light. Painted metal trigger with attached black electrical leads with battery terminals at end. Inscriptions on metal of lantern. PHLS0007.2 Hinged lid, wooden box painted army green to house signal light. Metal plate with inscription on front of box.PHLS0007.1 "D^D / LANTERN PORTABLE SIGNALLING / ADMIRALITY No 5110D / SERIAL No 5482 YEAR 943 / AMALGAMATED WIRELESS / A ASA LTD / 9792-100" •PHLS0007.2 "20 K4 transporting lantern / admirality pattern no 91108"

This portable, hand held visual signaling lamp, with trigger mechanism and inner reflective disk, was used for optical communication via Morse code, with the concave mirror tilted to focus the light into pulse signals. Larger versions of these lamps are fixed on ships or pedestals and have shutters in front of the light that are opened and closed to transmit signals. Smaller hand held versions like the Cape Nelson example have a concave mirror that is tilted to focus the light into pulse signals, and despite their size the lamps were renowned for their brilliant light. Invented by Arthur C W Aldis (1878‐1953) and pioneered by the British navy in the late nineteenth century, they continue to be used to the present day. Details on the Cape Nelson lamp include a serial number, a date of 1960 and the initials of the Department of Transport, which at that time incorporated the Commonwealth Lighthouse Service. Another lamp of the same date which is held at Wilsons Promontory was provided to the lighthouse by the Department of Shipping for signaling ships but was also used for communicating with Cliffy Island, 18 nautical miles away. Point Hicks also has an Aldis lamp and an associated case, which is painted an army green colour. A fourth lamp and case formerly at Cape Schanck disappeared from the collection sometime between 1995 and 2003. These types of lamps are not rare in museum collections.These types of lamps are not rare in museum collections however the Cape Nelson example has a reliable provenance to the lightstation and has first level contributory significance as a fine example of the Aldis lamps that were distributed to lightstations throughout Victoria and Australia.This object is comprised of a black metal encased Aldis lamp with electrical cord and associated wooden carrying case with metal clasp and red leather hand grip. yes
