Photograph


From the Collection of Geoffrey Kaye Museum of Anaesthetic History ANZCA House 630 St Kilda Road Melbourne Victoria

Description: Colour photograph of an Ormbsy inhaler lying on a wooden table. The inhaler has a metal mouthpiece with rubber tubing around the edge, and a rubber bag inside a black netbag.
Size: 28 x 20.2
Object Registration: 7268
Keywords: anaesthetic equipment, ormsby inhaler, inhaler, portable
Last updated: 2 May 2018 at 11:20AM

Junker's apparatus

Geoffrey Kaye Museum of Anaesthetic History, Melbourne

Glass jar with liquid measure markers etched onto. The jar has a metal lid, with a metal tube descending into the jar. Two metal tubes are protuding out of the top of the lid, and each has a small section of rubber tubing attached. There is also a metal hook, used to attached the jar to the physicians (anaesthetist's) lapel.

Historical information

Junker's inhalers are a "blow over" device used with a hand-held bellows to bubble air through liquid chlooform and to the patient. It was initially inteded for use with bichloride of methylene, a mixture of chloroform and methyl alcohol. Ferdinand Adalbert Junker introduced his inhaler in 1867 as appointed physician to Samaritan Free Hospital for Women (although it didn't have that name until c.1904).

Inscriptions & Markings

Stamped into frame of metal lid: LONDON MADE

Preview View Page

Eyebath

Geoffrey Kaye Museum of Anaesthetic History, Melbourne

Small glass container with a round base, extending into an oval shaped opening

Preview View Page

Mask, Julliard

Geoffrey Kaye Museum of Anaesthetic History, Melbourne

Large metal wire frame mask, covered in waxed paper, with gauze wrapped around the rim to prevent ether leaking out, effectively forming a rebreathing apparatus.

Historical information

This is a large metal framework covered in gauze, the whole mask completely enclosing the patient's face excluding any possibility of carbon dioxide being excreted. This object was found in the possession of the Italian Army in Libya in 1940, and donated to the museum by Dr Geoffrey Kaye. Gustave Julliard, of Geneva, after a death from chloroform had occurred in his practice, abandoned the use of that anaesthetic and adopted ether. He administered it from a large, wire frame, the outside of which was covered with waxed cloth to make it impermeable to air, the inside with surgical gauze on to which the ether was poured.

Preview View Page

Atomiser, De Vilbiss

Geoffrey Kaye Museum of Anaesthetic History, Melbourne

Red, heavy cardboard box with manufacturer's label at one end, containing a glass bottle with metal spray attachment, and a khaki rubber bulb for pumping liquid through the atomiser.

Historical information

Dr. Allen De Vilbiss (1841-1917) of Toledo, Ohio, developed his first atomiser around 1887. This device was designed to allow for dissolving cocaine, as a local anaesthetic agent, in oil, and spraying into the nose and throat. In the early to mid 20th Century, The DeVilbiss Company began making perfume atomisers instead of medical ones.

Inscriptions & Markings

Stamped into top of metal atomiser: DE VILBISS TOLEDO USA

Preview View Page

Funnel, glass

Geoffrey Kaye Museum of Anaesthetic History, Melbourne

Clear dimpled glass in the shape of a funnel, with red strong running through the centre, and tied to one side.

Historical information

A funnel, held above the patient's face, was almost the standard of giving oxygen until c.1930. It was quite useless, enriching the inhaled atmosphere by only about 3% of oxygen.

Preview View Page

Label, Cylinder

Geoffrey Kaye Museum of Anaesthetic History, Melbourne

Large unused diamond shaped Austox label made for use on nitrous oxide cylinders. Dark purple, violet and white background, with white, violet and red lettering.

Inscriptions & Markings

Information printed on label: SPECIALLY PREPARED FOR MEDICAL USES. / AUSTOX [logo] / NITROUS OXIDE / KEEP COOL / WEIGHTS: / GROSS..........LBS. ........OZS. / TARE.......... LBS. ........OZS. / NET..........LBS. ........OZS. / Contents Imp. Gallons / WARNING. - Great caution must be exercised to prevent any oil entering the cylinder, or being applied to the valve or fittings. The use of oil may lead to a dangerous explosion. / AUSTRALIAN OXYGEN / AND / INDUSTRIAL GASES / PTY. LTD. / MELBOURNE

Preview View Page

Label, Cylinder

Geoffrey Kaye Museum of Anaesthetic History, Melbourne

Large unused diamond shaped Austox label made for use on carbon dioxide cylinders. Black and beige background, with beige and red lettering.

Inscriptions & Markings

Information printed on label: SPECIALLY PREPARED FOR MEDICAL USES. / AUSTOX [logo] / COMPRESSED / CARBON DIOXIDE / KEEP COOL [in red] / WEIGHTS: / GROSS..........LBS. ........OZS. / TARE..........LBS. ........OZS. / NET..........LBS. .......OZS. / Contents Imp. Gallons / USE NO OIL OR GREASE ON VALVE [in red] / AUSTRALIAN OXYGEN / AND / INDUSTRIAL GASES / PTY. LTD. / MELBOURNE

Preview View Page

Label, Cylinder

Geoffrey Kaye Museum of Anaesthetic History, Melbourne

Large unused rectangular label made for use on carbon dioxide cylinders with 10% CO2 printed on it. Beige with black lettering.

Preview View Page

Label, Cylinder

Geoffrey Kaye Museum of Anaesthetic History, Melbourne

Large unused rectangular label made for use on carbon dioxide cylinders with 5% CO2 printed on it. Beige with black lettering.

Preview View Page

Label, Cylinder

Geoffrey Kaye Museum of Anaesthetic History, Melbourne

Large unused diamond shaped Austox label made for use on carbogen cylinders. Beige with a black border, and green and red lettering.

Inscriptions & Markings

Information printed on label: SPECIALLY PREPARED FOR MEDICAL USES. / AUSTOX [logo] / COMPRESSED / CARBOGEN / CO2..........% OXYGEN.......... / (The percentages stated above are subject to tolerance) / KEEP COOL [in red] / CONTENTS: Imperial Gallons / WARNING - Great caution must be exercised to prevent any oil entering the cylinder, or being applied to the valve or fittings. The use of oil may lead to a dangerous explosion. [in red] / Australian Oxygen & Industrial Gases / Pty. Ltd. / MELBOURNE

Preview View Page

Label, Cylinder

Geoffrey Kaye Museum of Anaesthetic History, Melbourne

Large unused hexagonal shaped CIG label made for use on carbogen cylinders. Beige and green background with black lettering.

Inscriptions & Markings

Information printed on label: CIG MEDICAL SECTION [logo] / OXYGEN 90% CARBON DIOXIDE 10% / (These Percentages are subject to a tolerance) / Contents..........Imp. Gallons / COMPRESSED / CARBOGEN / C.I.G. (Victoria) Pty. Ltd. / 550 Latrobe Street, Melbourne, C.3 / Telephone: FJ6681 / USE NO OIL / OR GREASE

Preview View Page

Label, Cylinder

Geoffrey Kaye Museum of Anaesthetic History, Melbourne

Large unused diamond shaped Austox label made for use on ethylene cylinders. Red with beige lettering.

Inscriptions & Markings

Information printed on label: AUSTOX [logo] / INFLAMMABLE / ETHYLENE / KEEP COOL / Product of the British Oxygen Co. Ltd. / Contents...............c.ft. ...............gallons (Imp.) / Weight of Full Cylinder ..........lbs. ..........ozs. / 31 OUNCES ETHYLENE = 166 1/2 GALLONS (IMPERIAL) / Use only moderate force when closing valve / Always test with water for leakage after using / Australian Oxygen & Industrial Gases / Pty. Ltd. / MELBOURNE

Preview View Page

Label, Cylinder

Geoffrey Kaye Museum of Anaesthetic History, Melbourne

Large unused diamond shaped Austox label made for use on ethylene cylinders. Beige with red lettering.

Inscriptions & Markings

Information printed on label: SPECIALLY PREPARED FOR MEDICAL USE / AUSTOX [logo] / INFLAMMABLE / ETHYLENE / KEEP COOL / Product of the OHIO CHEMICAL & MFG. CO., CLEVELAND. / Contents...............c.ft. ............... gallons (Imp.) / Weight of Full Cylinder ..........lbs. ..........ozs. / 31 OUNCES ETHYLENE = 166 1/2 GALLONS (IMPERIAL) / Use only moderate force when closing valve / Always test with water for leakage after using / Australian Oxygen & Industrial Gases / Pty. Ltd. / MELBOURNE

Preview View Page

Label, cylinder

Geoffrey Kaye Museum of Anaesthetic History, Melbourne

Medium sized diamond shaped label made for use on cyclopropane cylinders. White with a dark orange background and black and white lettering.

Inscriptions & Markings

Information printed on label: AUSTOX [logo] / INFLAMMABLE / CYCLOPROPANE / FOR ANAESTHESIA / KEEP COOL / (PRODUCT OF THE OHIO CHEMICAL & MFG. CO.) / CONTENTS: OZ. GALLONS (IMP.) / GROSS WT. CYLINDER LBS. OZS. / TARE WT. CYLINDER LBS. OZS. / AUSTRALIAN OXYGEN & INDUSTRIAL GASES / PTY. LTD. / 550 LATROBE STREET / MELBOURNE / C1

Preview View Page

Photograph

Geoffrey Kaye Museum of Anaesthetic History, Melbourne

Colour photograph of a Coutt's mask lying on a wooden table. The mask has a circular and made of metal and there is a small metal loop on the side of the object. Two thin metal hinges with screws are curved from one side of the mask to the other, and stuck on one hinge is a blue label with P.3.6 printed on it. Inside the mask is a metal mesh grill. A reddish brown residue like rubber and paper is stuck around the rim of the mask.

Preview View Page

Photograph

Geoffrey Kaye Museum of Anaesthetic History, Melbourne

Colour photograph of a Coutt's Mask lying on a wooden table. The mask is circular, made of metal and has a curved opening with a raised lip that is resting on the table. There is a small metal loop on the mask and a thin metal hinge with screws is curved from one side to the other. A reddish brown residue like rubber is stuck around the rim of the mask.

Preview View Page

Photograph

Geoffrey Kaye Museum of Anaesthetic History, Melbourne

Colour photograph of a modified Lidwill anaesthetic machine sitting on carpet, taken from above. The vaporiser is metal and circular, and has metal valves and controls and two orange tubes. The machine has an electric cord and power plug which is coiled on the floor.

Historical information

The Lidwill machine was designed by Mark Lidwill in 1913, for the purpose of mechanical or insufflation anaesthesia. It was manufactured by Elliott Bros. of Sydney. Shortly afterwards, the Anaesthetic and Portable Machine Company of Sydney devised a machine that was functionally the same but also contained an electric lamp heater.

Preview View Page

Photograph

Geoffrey Kaye Museum of Anaesthetic History, Melbourne

Colour photograph of a Bruck inhaler lying on its side on a wooden table. The metal inhaler is oval shaped with one half made of glass, and also has a vertical crosspiece. Lying next to the inhaler is a face mask and a filler for measuring ether.

Historical information

The Bruck Inhaler is a modification of the Clover Inhaler, designed by Lambert Bruck.

Preview View Page

Photograph

Geoffrey Kaye Museum of Anaesthetic History, Melbourne

Colour photograph of a Carter Braine modification of the Ormsby inhaler, sitting on a wooden table. The mask inhaler has a black rubber tubing around the mouthpiece, a metal cap and a wire net containing a natural sponge.

Historical information

The Ormsby inhaler was modified by Carter Braine in 1898.

Preview View Page

Photograph

Geoffrey Kaye Museum of Anaesthetic History, Melbourne

Colour photograph of a Lidwill anaesthetic machine sitting on carpet. A circular metal ether vaporiser sits on a brown wooden base, with brown tubes connecting to a trap bottle and metal valves, and a brown tube connected to the valve is coiled on the floor.

Historical information

The Lidwill machine was designed by Mark Lidwill in 1913, for the purpose of mechanical or insufflation anaesthesia. It was manufactured by Elliott Bros. of Sydney.

Preview View Page

Photograph
