Jig for holding a saw in the vice whilst it is being sharpened.
Tools are a file to sharpen and a bending gauge to "set" the saw teeth alternately each side of the centreline.
Home made jig in fair conditon
The Paynesville Maritime Museum has a collection of tools which were used to make and repair boats.
The tools are from several sources including local boat builders and their families.
