Produced by the SECV to document the Inner Joggle Plates.
Yields information regarding the dimensions of the Inner Joggle Plates for 90lb Lorain to 102lb BHP & 102lb BHP to 90lb Lorain.
SEC drawing number VW4/6, "Inner Joggle Plates. 90lb Lorain to 102lb BHP & 102lb BHP to 90lb Lorain. Tramways.". Drawn 07/1955. Beige paper copy of original dyeline print.
Copy of original.
