No. 127 is a 2'-gauge ex-South African Railways 'NGG16' class Beyer-Garratt locomotive. It was built by Beyer Peacock & Co of Manchester (builder's No.7428 of 1951) to their "Beyer Garratt" patented design of articulated steam locomotive. The South African Railways Class NG G16 2-6-2+2-6-2 of 1937 is a narrow gauge steam locomotive. Between 1937 and 1968, the South African Railways placed 34 Class NG G16 Garratt articulated steam locomotives with a 2-6-2+2-6-2 Double Prairie type wheel arrangement in service on the Avontuur Railway and on the Natal narrow gauge lines - The third order was for a further seven locomotives in 1951, numbered in the range from NG125 to NG131, once again from Beyer, Peacock. These and the subsequent locomotives had welded water and coal bunkers and flat-topped water tanks with rounded top side edges. The Beyer, Peacock locomotives ordered by the SAR, numbers NG109 to NG116 and NG125 to NG131, were shared more or less equally between the Natal and Avontuur lines No. 127 was purchased from the South African Railways by the Emerald Tourist Railway Board for the Puffing Billy Railway in late 2011 / early 2012, together with a container load of spare parts stripped from a derelict NGG16, and prepared for transport to Australia. The spare parts will assist in the restoration of sister NGG16 No.129 in the short term, while No.127 will provide the PBR with the option of restoring a second NGG16 at some future stage, if required. details from http://www.australiansteam.com/BP7428.htmHistoric - Overseas - South African - Narrow Gauge Railways - Steam Locomotive Garratt Steam Locomotive - 2-6-2+2-6-2 Beyer Peacock & Co NGG16 No.127 build No.7428puffing billy, ngg16, sar, beyer peacock & co garratt ngg16 no.127 build no7428, narrow gauge, steam locomotive, garratt

G42 Garratt Steam Locomotive Traffic and train loadings on Victoria's narrow gauge railways reached their peak during the 1920s. To assist in handling the longer, heavier trains, the Victorian Railways ordered two larger, more powerful Beyer Garratt locomotives. These were delivered in 1926 and were numbered G41 and G42. They were sent to work on the Colac–Beech Forest–Crowes line and the Moe–Walhalla line respectively. After the line from Moe closed in 1954, G42 was sent to Colac, where it worked with its mate, G41, until closure of that line in mid-1962. G41 had been in poor condition and was scrapped, whereas a brighter future awaited G42. The Victorian Railways offered G42 to the Puffing Billy Preservation Society, for display as a static exhibit in the Menzies Creek Museum. Over time, a plan evolved to restore G42 to operation, a goal that was eventually achieved by the launch of G42 back into traffic in April 2004. G42 now continues to operate as a restored member of the Puffing Billy Railway's locomotive fleet. No. originally constructed: 2 No. in service: 1 (No. 42) Boiler pressure: (lb/sq. in) 180 Boiler heating surface: 1268 sq ft (117.8 m2) Tractive effort: (85%) 26,860 lbs (12.18 t) Driving wheel diameter: 36" (91.44 cm) Max axle load: 9t 5cwt Length Overall: 51' 7" (15.72m) Height Overall: 10' 8" (3.28m) Date of manufacture: 1926 Manufacturer: Beyer Peacock Place of manufacture: Manchester UK Locomotive Type: Garratt Coal capacity: 70 cwt Cylinder diameter: 13" (33.02 cm) Cylinder stroke: 18" (45.72 cm) Wheel arrangement: 2-6-0+0-6-2 Roadworthy weight: 69t Water capacity: 1680 gal (7,637.43 l) Beyer Peacock - Garratt Locomotives Register Works Number - 6268 / 1926 Gauge/Railway/Class - 2'6"/Victorian Government Rlys/G Type - 2-6-0+0-6-2 No. G42 Notes - Australia G42 Built in 1926 and painted all-over black, this Garratt locomotive was issued to the Moe to Walhalla line where it remained—other than for overhauls—until the line closed in 1954. After an overhaul at Newport Workshops, it was issued to the Colac to Crowes line and remained there until that line closed in 1962 when it was returned to Newport Workshops for storage. In 1964 it was sold to the Puffing Billy Preservation Society and removed from the V.R. register 3 months later. It arrived at Belgrave in 1968 and was hauled to Menzies Creek for static display in the museum. 1986 saw the commencement of restoration the Belgrave workshops and has been restored to its 1946 to 1954 condition with raised cab roof, raised marker lamps, steel cow-catchers and all-over black livery. It was returned to service on April 18, 2004. Service History : Jun 1926 - Moe - initial allocation of a new locomotive Jun 1926 - Oct 1954 Moe Oct 1954 - Jan 1955 Workshops Jun 1955 - May 1962 Colac Jul 1962 - Dec 1965 Workshops - Stored Jan 1968 - Feb 1968 Belgrave - Stored Feb 1968 - 1982 - Menzies Creek Steam Museum 1982 - 2004 - Under restoration Apr 2004 - Belgrave - In active service at Puffing Billy Railway BelgraveHistoric - Victorian Railways - Narrow Gauge - Garratt Steam Locomotive - G42 Victorian Heritage Register (VHR) Number H2187 G42 Garratt Steam Locomotive made of steel, iron and wrought iron with brass fittings - the Locomotive is in Active Service - Belgrave Station G42puffing billy, narrow gauge, garratt, g42, steam locomotive, beyer peacock, victorian railways

Digital TIFF file Scan of 35mm Ilford FP3 black and white negative transparencyfyansford cement works railway, garratt locomotive, george coop collection

Digital TIFF file Scan of 35mm Ilford FP3 black and white negative transparencyfyansford cement works railway, garratt locomotive, george coop collection

Digital TIFF file Scan of 35mm Ilford FP3 black and white negative transparencyfyansford cement works railway, garratt locomotive, george coop collection

Digital TIFF file Scan of 35mm Ilford FP3 black and white negative transparencyfyansford cement works railway, garratt locomotive, george coop collection

Digital TIFF file Scan of 35mm Ilford FP3 black and white negative transparencyfyansford cement works railway, garratt locomotive, george coop collection

Digital TIFF file Scan of 35mm Ilford FP3 black and white negative transparencyfyansford cement works railway, garratt locomotive, george coop collection

Digital TIFF file Scan of 35mm Kodachrome colour positive transparency mounted in cardboard Kodachrome mountProcessing date FEB 64fyansford, fyansford cement works railway, garratt locomotive, george coop collection

Digital TIFF file Scan of 35mm Kodachrome colour positive transparency mounted in cardboard Kodachrome mountProcessing date FEB 64fyansford, fyansford cement works railway, garratt locomotive, george coop collection

Narrow gauge private railwayDigital TIFF file Scan of 35mm Ilford FP3 black and white transparencyfyansford cement works railway, garratt locomotive, geelong, george coop collection

Narrow gauge private railwayDigital TIFF file Scan of 35mm Ilford FP3 black and white transparencycement works railway, garratt locomotive, geelong, george coop collection

Narrow gauge private railwayDigital TIFF file Scan of 35mm Ilford FP3 black and white transparencyfyansford cement works railway, garratt locomotive, geelong, george coop collection

Narrow gauge private railwayDigital TIFF file Scan of 35mm Ilford FP3 black and white transparencyfyansford cement works railway, garratt locomotive, geelong, george coop collection

Narrow gauge private railwayDigital TIFF file Scan of 35mm Ilford FP3 black and white transparencyfyansford cement works railway, garratt locomotive, geelong, george coop collection

Narrow gauge private railwayDigital TIFF file Scan of 35mm Ilford FP3 black and white transparencyfyansford cement works railway, garratt locomotive, geelong, george coop collection

Narrow gauge private railwayDigital TIFF file Scan of 35mm Ilford FP3 black and white transparencyfyansford cement works railway, garratt locomotive, geelong, george coop collection

Narrow gauge private railwayDigital TIFF file Scan of 35mm Ilford FP3 black and white transparencyfyansford cement works railway, garratt locomotive, geelong, george coop collection

Steam Locomotive - 2-6-2 2-6-2 Beyer Peacock & Co Garratt NGG16 No.129 build No. 7430 Loco - Garratt NG129 Date acquired - 1996 Acquired from - South African Railways State when acquired - Work done - Currently being rebuilt to 2 ft 6 in (762 mm) gauge as a backup for G42. Expected Return to service in 2019. Restored to service - Current State - Currently being Rebuilt It was built by Beyer Peacock & Co of Manchester (builder's No.7430 of 1951) to their "Beyer Garratt" patented design of articulated steam locomotive. The South African Railways Class NG G16 2-6-2+2-6-2 of 1937 is a narrow gauge steam locomotive. Between 1937 and 1968, the South African Railways placed 34 Class NG G16 Garratt articulated steam locomotives with a 2-6-2+2-6-2 Double Prairie type wheel arrangement in service on the Avontuur Railway and on the Natal narrow gauge lines - The third order was for a further seven locomotives in 1951, numbered in the range from NG125 to NG131, once again from Beyer, Peacock. These and the subsequent locomotives had welded water and coal bunkers and flat-topped water tanks with rounded top side edges. The Beyer, Peacock locomotives ordered by the SAR, numbers NG109 to NG116 and NG125 to NG131, were shared more or less equally between the Natal and Avontuur lines Historic - Overseas - South African - Narrow Gauge Railways - Steam LocomotiveSteam Locomotive - 2-6-2+2-6-2 Beyer Peacock & Co Garratt NGG16 No.129 build No.7430 made of steel, wrought iron and ironpuffing billy, beyer peacock, beyer peacock & co garratt ngg16 no.129 build no.7430, narrow gauge, steam locomotive, garratt locomotive, garratt ng129, garratt ngg16 no.129

Narrow gauge private railwayDigital TIFF file Scan of 35mm Ilford FP3 black and white transparencyaustralian standard garratt steam locomotive, fyansford cement works railway, george coop collection

The G42 Garratt Steam Locomotive was one of two heavier more powerful locomotives that operated on Victoria's narrow gauge railways. These Beyer Garratt locomotives were built in Manchester, England and delivered in 1926. They were numbered G41 and G42. They operated on the Colac–Beech Forest–Crowes line and the Moe–Walhalla line respectively. After the line from Moe closed in 1954, G42 was sent to Colac, where it worked until closure of that line in mid-1962. At that time the G41 was in poor condition and was scrapped. G42 was offered to the Puffing Billy Preservation Society.A black and white photocopy of a goods train and carriages.surrey hills, trains, goods carriages, g42 garratt steam locomotive, puffing billy preservation society, victorian railways

Railway systems have methods by which trains can proceed in safety from station to station, free from the risk of collision with other trains. These methods are generally known as "Safeworking" and they particularly apply to trains on single lines where trains run in opposite directions. The stations between these two sections are called crossing stations. A "Train Staff", a thick, round metal rod, bearing the name of the two stations is issued and these places are designated as Train Staff stations. No train is permitted to proceed through the section unless the train driver either takes the staff for the section into his possession or personally sights the staff. (Note that every station on the line is not a crossing station. These roles were performed at Barongarook, Gellibrand, Banool, Beech Forest, Wyelangta, Weeaproinah and Crowes.) Except for the period 1927-1939 when Train Section Orders were applied instead, due to declining business Train Staff and Ticket working was used throughout on the line.B/W. Driver Bill Brady holding the Train Staff in the cabin of Garratt locomotive G42, at Weeaproinah 1961 railways, bill brady, train driver, weeaproinah, train staff

an original Great Train Race publicity sign - from inaugural first great train race held on 16 May 1982 ran by the Puffing Billy Preservation society to raise funds for the restoration of G42 Garratt Locomotive Historic - Puffing Billy Railway - PBRS fPublicity event signGreat Train Race Sign - Black printed ink Paper sign glued on to Masonite wood The Great Train Race - 16 May 1982 - 13.5km Belgrave to Emerald Lake a fun run with a difference - "Race Puffing Billy " can you beat Victorias famous 76 year old train ? are you fit enough? Start 9 am at Belgrave Railway Station and enjoy a Sunday morning jog thru the scenic Dandenongs - join your family & friends at beautiful emerald lake finish - enjoy BBQ facilities & other family attractions Prizes outright winner ( not Puffing Billy ) will receive two return tickets to USA on Pan Am Team Prize the four runners with the fastest aggregate team time will each win a return air ticket to Sydney on TAA to compete in the 1982 "the Sun City to surf" Random draws of entrants will be made at 11Am for the many other valuable;e prizes - all proceeds to aid the restoration of Puffing Billy's big brother G42 PAN AM TAA Trans Australia Airlines

The Victorian Railways "G" class Beyer-Garratt locomotives had 2 foot 6 inch gauge engines of the 2-6-0 + 0-6-2 wheel arrangement, that is it had a tender in front of the engine and a tender behind. Two people are riding on the tender in front while a crewman is mounting the engine.B/W. Engine G42, with a crewman entering, and a NUU louvre van, in front of a pulp wood stack. Two people are mounted on the articulated section of the locomotive. Two empty tracks in front.beech forest; railway; loco g42;

To a dead end spur at Beech Forest station a locomotive depot was provided with a coal stage, ash pit and water tank as part of the original facilities of the station. Coal was transported from Colac by rail and hand-shovelled up onto the stage from an NQ truck positioned alongside. Twin water columns on the stage ends enabled two NA class or both ends of a Garratt locomotive to take water simultaneously. Beneath the trestle was the ash pit.B/W. 200mm x 271mm. An NA locomotive on trestles taking coal at Beech Forest. A child watches.beech forest; railways; coal stage; na locomotive;

By July 1960 for the Beech Forest railway outwards traffic was down to 12,730 tonnes per year, and from Ferguson under 1,000 tonnes per year. One wagon was all that was needed in July to reach Beech Forest The line kilometre proportion of $26,320 was sufficient in itself to justify the withdrawal of the rail service, without the fact that reconditioning the two Garratt locomotives and rendering serviceable the ancient wagons would make the costs prohibitive. As a result the whole line closed in June 1962.Colour. 144mm x 279mm. G42 locomotive with Weeaproinah goods in a loaded NQR wagon and NC guard's van, between Beech Forest and Ferguson in July 1960.ferguson: beech forest; railways;

Constructed during the overhaul of locomotive G 42 in 1954/1955. This stack was the exhaust for the coal fired Garratt locomotive G 42 and replaced the ornate stack it had been built with by Beyer Peacock in England in 1926. The overhaul was carried out between it's last run on the Moe to Walhalla railway and prior to locomotive being placed in service, for the first time, on the Colac to Beech Forest railway line. The stack remained in use until 1962, when the locomotive was withdrawn, and was still connected to the boiler until restoration of G 42 was undertaken. Locomotive G 42, with its replica ornate stack, was restored by the Puffing Billy Preservation Society in 2004 and can be seen operating on the Puffing Billy Railway. G 42 Stack - era 1955G 42 Stack - era 1955 made of cast Metal

The Q class were introduced as bogie flatwagons in the 1870's. Large Q wagons as shown were built to the 1920's In the early 1900's, some Q wagons were modified for Pintsch Gas traffic with a small pump motor cabin at one end and a tank for carrying the gas. Other conversions for traffic were as required. Examples were: sheet glass, skeletal underframes between workshops In 1926 the railways built two narrow gauge Garratt locomotives. As normal wagons were unsuitable for moving these locomotives a special skeletal wagon was built. The engines were split into units for transportation. It featured axle bearings and boxes from steam engines, had hinged buffers that could drop out of the way during loading/unloading. It also featured 'strap' rail along the deck. The wagon was Q 129. This wagon was also available for general narrow gauge rolling stock. Q wagons were numbered from 1 to 136. Service History: *Q 129.VA - 1/ 6/1926 NWS Built new H/brake & drop buffers. For traffic of Narrow Guage stock 31/ 1/1931 NWS Into Workshops - 16/ 6/1931 NWS Out of Workshops (50 days) 6/11/1931 NWS Into Workshops - 27/11/1931 NWS Out of Workshops (22 days) 24/ 8/1936 NWS Into Workshops - 10/ 9/1936 NWS Out of Workshops (18 days) 27/11/1936 NWS Into Workshops - 26/ 2/1937 NWS Out of Workshops (Light repairs) circa 1960 - Photograph SL20 p32, loaded with 7NA / /1975 - Photograph #393 / /1976 - Photograph #553, #554 19/ 3/1979 - Condemned - 10/ 4/1979 - Off Register - 10/ 4/1979 - Sold (to) ETR, Belgrave / /1989 EME Body [GRE]. [SXC]: 29/3/92, MEL127E5, Puffing Billy at station Historic - Victorian Railways - Transporter wagon used to carry and transfer 2' 6" Narrow gauge rolling stock over Victorian broad gauge (1,600 mm (5 ft 3 in) main lines to the narrow gauge lines. Q 129 was unique, it was built to transport narrow gauge locomotives. Transporter Wagon made of Steel and wrought Iron129Q129q, puffing billy, transporter wagon

Victoria's narrow gauge railways were from Wangaratta to Whitfield (covering 30.5 miles/49 km) opening in 1899, Colac to Beech Forest (29 miles/46.7 km) opening in 1902 with an addition to Crowes (14.1 miles/22.7 km) opening in 1910, Upper Ferntree Gully to Gembrook (18.2 miles/29.3 km) opening in 1900, and Moe to Walhalla (26 miles/41.3 km) opening in 1910. From the outset these narrow gauge lines proved very uneconomical in operation and were plagued with continuing financial losses. The lines most difficult to work were those carrying the most business, and in particular the trains from Colac and Moe with their 1 in 30 grades and countless curves precluded having engines with large coupled driving wheels operating. Having examined the possible use of articulated locomotives to reduce operating costs on the narrow gauge lines the Victorian Railways decided upon the Beyer-Garratt type of locomotive in 1925 and an order was placed in England for two engines of the 2-6-0 plus 0-6-2 wheel arrangements. These arrived in April 1926. Assembly of the new Garratts was duly completed and steaming trials carried out at Newport, Victoria, the engines being classed as "G" and given the running numbers "41" and "42". G41 was taken to Colac where, on 5 June 1926, it was put to work on the Colac-Beech Forest-Crowes line. G42 soon followed and duly began work on the equally steep and tortuous but shorter Moe-Walhalla line. Following the closure of the Moe line in 1955 G42 was refurbished and went to Colac. G41 was overhauled, but not as thoroughly as G42, at then returned to Colac where both Garratts shared regular work on the line until its closure in 1962. From 1978 G42 continues its operation on the Upper Ferntree Gully-Gembrook line as part of the Puffing Billy Preservation Society.G42: Puffing Billy's Big Brother. Pictorial history of a Beyer-Garratt in Victoria, Australia. Phil A'Vard, Larry James, Ron Peach (concept). Puffing Billy Preservation Society; Belgrave (Vic); 1980. 64 p.; illus; map. Soft cover. ISBN 0 9598392 7 5victorian railways; narrow gauge; moe; walhalla; colac; beech forest; crowes; upper ferntree gully; gembrook; beyer-garratt;

24 page magazine, publisher by Traction publication recording current event in Australia & New Zealand railways & tramways - with photos, advertisements, see list for contents. Railways in Australia The Magazine about Australian Trains, incorporating TRAM TRACKS, the Electric Traction Monthly Contents (Summary) Articles New Zealand Railways - Record Year - pl, 2 and 3 Diesel operation of South line is SAR plan - p2 Comrails plan big improvements - p3 New north line soon for NSWR? - p3 About Locomotives - QGR Garratt's, VR N class, R class, NSW 58, TGR diesels - p4 and 5 Holiday by Rail - C.Einsiedel - Vic and NSW Comparisons are Odious - An American View - PCC tram for MMTB - p9 More Fare increase - Sydney, Melbourne and elsewhere - p10 Operation 'Strike' - Melbourne Trams Handle Crowds - by KSK - p 1 2 and 13 (VR trains on strike) - very interesting. - has map of ~B including authorised lines. High Voltage ~ Electric Railway news - NSW, VR, Gippsland - p 14 Model Railways in Australia - p 1 8 and 19 The Mayfield Lines ( large garden 0 gauge model railway, by L.A. Clark, includes plan - p20 and 2 I.) Photographs NSW steam loco 5801 - pl TGR diesel railcars built by Comeng - p3 NSW 38's - p4 MMTB PCC tram 980 and interior view - p9 Photo of St Louis Car Co. B3 bogie used under PCC car - p10 Perth Trolley Bus - No. 41 - p 1 3 Advertisements McGills Newsagency - p2 John C. Beckett - photographer - p6 Meadmores model engineering Co. - p6 and p 14 WAGR institute magazine - p6 Wattle Park - p7 Australian Model Hobbies - SA - p 1 5 Traction Publications - p 1 5 The Main Hobby Depot - Melbourne - p 1 5 Railway Destination Rolls, LA Clark - pl 5 Model repairs - R.Pearson - p19 Hearn's Hobbies- p21 The Hobby Shop p21 Herbert Small - p21 Australia Railway Models - p22 Scale Model Railway Equipment - p23 Bames Tennis Centre - p23 Traction publications listings and books etc. - p24 - and where to purchase magazine. Amalgamated Blind and Tent Co. - p24 Other List of office bearers and general information for ARLHS Obituary for Maj Gen. A.C.Fewtrell Chief Civil Engineer for NSWGR Tramway news - Sydney King St. Closure, Wanganui system closure, Latrobe St. Melbourne, Melbourne VR trams, SEC trams purchasing maximum traction trams, Launceston, Hobart, Kalgoorlie - p I 1, Brisbane, Perth and Adelaide - p I 5 Drawing of Adelaide H class trams - p 1 9 Club noticeboard, and Question box - on Outer circle Railway. Wad 25.11.95 Record images added 20/8/2013. trams, tramways, australian railways, new zealand railways, model railways, model tramways
