Document or memo dated 9/1/1949 - hand written on paper for typing by the Correspondence Branch of the SECV, Metropolitan branch from T H Thomas DTS, to Engineer and Manager, titled "Tail Lights" about the fitting of tail lights to tramcars on the three Provincial tramways. Notes the delays in receiving materials that had been ordered, but preliminary work had been carried out with, batteries received from Sydney and that all tramcars would be fitted by the end of the year.Yields information about the modifications proposed to the tramcars to provide a rear tail light and lights when at a terminus.Hand written draft on SECV draft letter paper - for typing.tramcars, safety, tail lights, lights

Hand written note or timeline of the fitting of tail lights to trams written by T H Thomas from 2-11-1949 to 24/1/1950 setting out the instructions to depots, delivery of materials, inspection of installations, placing orders, issues obtaining batteries, and other materials, and the number of trams completed in each city as at 20-1-1950. See also item 10053 for another memo by W H Thomas.Yields information about the modifications proposed to the tramcars to provide a rear tail light and lights when at a terminus.Hand written note on two plain foolscap sheets.tramcars, safety, tail lights, lights, geelong depot, bendigo, ballarat

Note or letter dated 10-10-49, from a Mr Russell to Mr Thomas regarding the installation of tail lights to trams and the annual cost of running these. Suggests using the compressor circuit for this instead. Has a sketch showing the proposed wiring diagram including a battery, which, when the compressor was running would be sufficient to charge the battery. See also item 10046 for a drawing showing this. The smaller hand written notes provide further info and costs.Yields information about the development of a system to install tail lights on tramcars.Set of three documents, hand written on paper.tramcars, tail lights, electrical engineering

Yields information about the SEC tram fleet when tail lights fitted and saloon seat types.Handwritten list, over two sheets, of SEC Tramcars through to No. 40, of the fitting date of tail lights, and notes regarding the lights and a list of the saloon seating types in the single truckers and ceiling colours in the bogie trams. Contained within Reg Item 5507 - Foolscap binder with green covers, black binding edge and metal clips. sec, tramcars, lights, seats, ceilings

Set of copies of 13 SEC Purchase orders for the purchase of items or equipment for the installation of tail lights onto tramcars - December 1949. Notes how the items were to be delivered to Bendigo, Ballarat or Geelong - generally by Passenger train. Gives name of company, number of items to be delivered and pricing. All orders authorised by C C Boardman.Yields information about the purchasing of equipment for the installation of tail lights on tramcars, the variety of suppliers and how the items were to be delivered.Set of 13 copies of purchase orders, typed with punch holes on the left hand edge.tramcars, tail lights, electrical engineering, electrical equipment

Memo dated 31-11-1949 from the Depot Foreman Geelong, Mr V Phillipps to Mr Cuggan regarding the fitting of a new contact on the horn relay to prevent damage or breaking the red tail lights and the armature of the relay sticking down. Notes about which trams used on and the number of circuits. Also notes the future use on bogie cars.Yields information about the modifications proposed to the tramcars to provide a rear tail light and lights when at a terminus.Hand written memo on SECV printed departmental paper.tramcars, safety, tail lights, lights, geelong depot

Set of two drawings (BA-T8-8100/1 and BA-T8-8100B) showing the installation of tail lights on SEC tramcars and modifications to the battery/trolley pole relay and battery. Both are dated 15/11/1949 and signed by the Manager Ballarat Branch. The actual relay used later was a Post Office type relay contained within a wooden box. See item 10052 for an associated memo and an earlier version of the drawing.Yields information about the modifications proposed to the tramcars to provide a rear tail light and lights when at a terminus.Drawing - dyeline print on plain papertramcars, safety, tail lights, lights, ballarat

The drawing titled "Ballarat Rolling Stock Wiring Diagram - Existing and Proposed Tail Light Installation" shows wiring for both single-truckers and bogie trams. Shows switches, lights, and wiring layout. Does not include a battery that was actually installed. Drawing undated, possibly c1949.Yields information about possible wiring of tail lights in Ballarat trams.Foolscap drawing - faded, undatedsecv, ballarat, tail lights, electrical engineering

Drawing titled "Tramcars tail light and battery charging arrangement", shows battery charging arrangement using the compressor circuit / motor as a resistance. Marked up for switches and compressor. This option was not implemented. Possibly prepared in the Geelong office. See also item 10051 for an associated letter.Yields information about the development of a system to install tail lights on tramcars.Drawing - dyeline printed, dated 20-9-1949 titled "Tramcars tail light and battery charging arrangement", Drawing 8357.tramcars, tail lights, electrical engineering

Drawings 1 - "Tramcars tail lamp and battery charging arrangement" 2 - "Tramcar tail lamp installation, relay modification" Shows the existing interior lamp circuits and the additional wiring required to provide tail lamps using horn-type relays, along with additional lamps and a battery. Second drawing shows modification to the relays. This type of equipment was not used on Ballarat tramcars.Yields information about the development of a system to install tail lights on tramcars.Set of two foolscap drawings, copied using blue carbon paper.tramcars, tail lights, electrical engineering

Drawing untitled and undated, shows the proposed wiring arrangement for Geelong trams 1 to 10, 16 to 23, and 24 to 26. Similar to the wiring arrangement shown in item 10047.Yields information about the development of a system to install tail lights on tramcars.Foolscap ruled paper, drawing prepared using pencil.tramcars, tail lights, electrical engineering

The extent of exterior changes veered not much further than a redesigned Holden logo and wheel trims. An updated Ecotec (Emissions and Consumption Optimisation through TEChnology) version of the Buick V6 engine coincided with the changes to the engine in the United States. The Ecotec engine packed 13 percent more power, an increase of 17 kilowatts (23 hp) over the VR, cut fuel consumption by 5 percent, and increased the compression ratio from 9.0:1 to 9.4:1. Holden mated the new engine with a modified version of the GM 4L60-E automatic transmission, bringing improved throttle response and smoother changes between gearsThe VS Commodore was the last of which to be sold as Toyota Lexcens, as Holden and Toyota ended their model-sharing scheme The last Lexcens were built during 1997This model was also sold between 1995 and 1997 in small numbers to Malaysia and Singapore as the Opel Calais.4 door sedan VS Commodore sedanLion and stone badge on Bonnet and on Boot centre, Commore on both mudguards Holden badge on Rear under tail lightsvehicle, vs commodore, car

Item used to switch on or off the red tail lights circuit on a tram. Made by the SECV. The board was located next to the 6V battery that was used to power the tram tail lights when the trolley pole was being reversed under a passenger seat.. Demonstrates an item fitted to a tramcar to switch an external lighting circuit.Softwood wood board with a bakelite two pole switch marked "on" and "off" and a Federal 250V 15A rewireable ceramic fuse attached. Has remnants of cloth covered copper wire on the rear. See item 9024 for an associated drawing."12" in blue pencil.fuse, tram 14, tramcars, tramcar maintenance, electrical switching

The photograph shows SEC Ballarat tram No. 33 (Gardens via Drummond St North) and No. 12 (Mt Pleasant) crossing each other in Wendouree Parade, mid 1950s with tail lights installed. Photographer unknown.Yields information about tram 33 tram 12 during the mid 1950s in Wendoure Parade.Black and white print with plain back.tramcars, tram 33, wendouree parade, tram 12

There were a number of minor up-grades over the superceded HQ model, and they included infinitely adjustable windscreen wipers and the introduction of pollution equipment .Other features included a bolder grille and body mounted rear tail lightsA significant improvement over the original HQ on which this car was basedAutumn gold coloured 4 door sedan with a beige vinyl roof.Holden Lion and Rock logo on rear roof pillars, Premier badge on black strip across lower boot lid, 4.2 litre badge on boot lid and Premier on rear of both front mudguards. .Number plate Club permit 63462 Hvehicle, hj model, premier, car

The photograph shows SEC Ballarat tram No. 35 northbound in Lydiard St loop, crossing another bogie tram, probably at the Seymour St Loop. The tram is fitted with tail lights and large reflective triangles, indicating a date between 1956 and 1960. Photographer unknown.Yields information about tram 35 crossing another bogie, probably at the Seymour St loop - late 1950s.Black and white print on plain papertramcars, tram 35, lydiard st nth

The photograph shows SEC Ballarat tram No. 33 (Gardens via Drummond St North) in lower Sturt St mid 1950s with tail lights installed. In the background is the Ballaarat Gas Co. building, Patersons, a hotel and the Ballarat Mechanics Institute Building with signs for Robur Tea and Davies Bread. Photographer unknown.Yields information about tram 33 and lower Sturt St mid 1950s.Black and white print with plain back.tramcars, tram 33, sturt st

The photograph shows SEC Ballarat tram No. 35 at the City terminus before proceeding to Lydiard St North. A single-truck or small tram is behind. The conductor is standing by the tram stop pole. The tram has been fitted with tail lights and reflective triangles from 1956 to 1960. Photographer unknown. In the background is the Ballarat Town Hall.Yields information about tram 35 in Sturt St - late 1950s.Colour print on plain paper - set of twotramcars, tram 35, sturt st, town hall

Black and White print contained within the Wal Jack Bendigo and Geelong Album, see Reg Item 5003 for more details. Photo of Bendigo Birney No. 11 at Bendigo depot alongside Bendigo 3, 10-4-1950, photo by Keith Kings. Alongside the tram is a man wearing a hat. Has in the background tramcar body jacks and other equipment including wheelsets. IN an email from John Radcliffe 14/10/2019, the "man in a hat" is Wal Jack. On the rear in blue ink "Bendigo, Birney No. 11, Open Combination No. 3, Note: Tail Lights, Depot." In bottom left hand corner "10/4/50". In top right hand corner is the Keith Kings copyright stamp with number "D(2)(viii)" written in.trams, tramways, bendigo, birney, depot, tram 11, tram 3

Photograph of Victorian Railways built tram No. 53 which was sold to the MMTB following closure of the St Kilda - Brighton Beach line in 1959. Modified by the MMTB, as VR class tram No. 53 and generally used on the Moonee Ponds to Footscray route 82. This photo shows the tram in River St after being fitted with tail lights in Feb. 1973 and before being renumbered to tram 700 in Oct. 1976Yields information about VR class tram 53Colour print on Kodak paper with black borders. trams, tramways, river st, route 82, vr class, tram 53

Black and white negative by Wal Jack of SW6 850 (Prahran, route 77), leaving the Batman Ave terminus at Princes Bridge. Has tail lights and dash canopy lighting with the sign "This is you car use it" underneath. The front number can just be seen. Note the parked taxis and drivers on the south side of the roadway. See also Reg Item 5244 for a photo of the tram at the terminus.trams, tramways, princes bridge, sw6 class, dash canopy lights, new tramcars, batman ave, tram 850

Item used to switch the power for the red tail lights circuit from the trolley pole to the battery circuit when the trolley pole was being reversed and not able to provide power to the internal and external lights. Made by the SECV. Salvaged from tram 14 during the project to renew the wiring and electrical arrangements of the tram. The box was located adjacent to the driver's windows and would click when the trolley pole was placed back on the overhead.Demonstrates an item fitted to a tramcar to switch an external battery tail lighting circuit.Wooden box made from softwood with bevelled corners, plywood top painted green containing an 8 Ohm "Post Office" type relay (see reference) fitted with two "break" contacts and associated insulated wiring soldered to the relevant contacts. See item 9024 for an associated drawing. Two examples held.fuse, tram 14, tramcars, tramcar maintenance, electrical switching

The photograph shows SEC Ballarat tram No. 35 reversing at the Lydiard St North x-over opposite the Post Office. The driver is preparing to lift the trolley pole, while the conductor is standing alongside the tram. The tram has the destination of City and has been fitted with tail lights and large reflective triangles - from 1956 to 1960. In the background are the Post Office and the Ballarat Mining Exchange building fitted with Mobil gas petrol bowsers. Photographer and date unknown.Yields information about tram 35 reversing at the Lydiard St Nth crossover opposite the Post Office - late 1950s.Black and white print on plain papertramcars, tram 35, lydiard st nth, city, mining exchange, post office

Photograph of SW6 850, at South Melbourne depot, side on view. Made by Sutcliffe of 94 Elizabeth St Melbourne for the MMTB. See also Reg Items 674 and 3426 for other photos, probably taken at the same time.Yields information about SW6 850 when new in 1939.Photograph, Black and White, two copies held.In ink on the rear: Copy 1 - M&MTB SA 948, SW6 850, South Melbourne Depot 1939" Copy 2 - M&MTB SW6 850, Note: Roller bearing in lieu of axle boxes brasses, tail lights . ?Hanna St Depot, March 1939" Has Keith Kings stamp "SA 225".trams, tramways, sw6 class, tram 850

Black and white photograph of the first of SW6 class tramcars, No. 850 at South Melbourne Depot following its construction showing the tail light and the dash canopy lighting. The photograph does not have the sign "This is your car use it" as shown on the other official photograph of this tram - see page 41 of the 5th Edition of Destination City. Tram shows route 77 with the destination of Special. Photograph by Sutcliffe Pty Ltd, Illustrative Photographers of 94 Elizabeth St Melbourne. .1 - as above - from the Keith Kings collection - added 4/4/2019. .2 - as above but with the sign "This is your car use it" - added 4/4/2019. See Reg Item 3558 for another print within an album.Stamped on rear in red, with the photo number in black "Sutcliffe Pty Ltd, / Illustrative Photographers / No. 3 / 94 Elizabeth St Melbourne / CENT 1500 - 2601" (Their Melbourne central exchange phone number) .1 - Has the photographers stamp, along with Keith's details in ink on the rear "M&MTB S-A947 / SW6 - 850 / South Melbourne Depot 1939 / Note: Tail-lights & Dash Canopy Lighting, Roller Bearing Axle Boxes". Date stamp 12 Jan. 1948. .2 - Has the photographers stamp, along with Keith's details in ink on the rear "M&MTB S-A946 / SW6 - 850 / South Melbourne Depot 1939 / Note: Tail-lights & Dash Canopy Lighting, Dash Advert, Roller Bearing Axle Boxes". Date stamp 12 Jan. 1948.trams, tramways, mmtb, sw6 class, new trams, south melbourne depot, route 77, tram 850

Black and white negative by Wal Jack of SW6 class 850 at the Princes Bridge terminus. The tram entered service 31/3/1939. Photo c1940. The microphone can be seen in the front window. Note no windscreen wiper. Tram running a route 77, Prahran. Has tail lights and dash canopy lighting with the sign "This is you car use it" underneath. The front number can just be seen. In Swanston St and adjacent are W2's. Other photos of the tram in the album are dated 1939, possibly late 1939 given it appears to a summer's day.trams, tramways, shelters, princes bridge, sw6 class, dash canopy lights, new tramcars, batman ave, tram 850
